100 Unidrive M702 User Guide
Issue Number: 3
6.2 Parameter descriptions
6.2.1 Pr mm.000
Pr mm.000 is available in all menus, commonly used functions are provided as text strings in Pr mm.000 shown in Table 6-1. The functions in Table
6-1 can also be selected by entering the appropriate numeric values (as shown in Table 6-2) in Pr mm.000. For example, enter 7001 in Pr mm.000 to
erase the file in NV media card location 001.
Table 6-1 Commonly used functions in xx.000
Value Equivalent value String Action
00
[No Action]
1000 1 [Save parameters] Save parameters when under voltage is not active and low voltage threshold is not active
6001 2
[Load file 1] Load the drive parameters or user program file from NV media card file 001
4001 3
[Save to file 1] Transfer the drive parameters to parameter file 001
6002 4
[Load file 2] Load the drive parameters or user program file from NV media card file 002
4002 5
[Save to file 2] Transfer the drive parameters to parameter file 002
6003 6
[Load file 3] Load the drive parameters or user program file from NV media card file 003
4003 7
[Save to file 3] Transfer the drive parameters to parameter file 003
12000 8
[Show non-default] Displays parameters that are different from defaults
12001 9
[Destinations] Displays parameters that are set
1233 10
[Reset 50Hz Defs] Load parameters with standard (50 Hz) defaults
1244 11
[Reset 60Hz Defs] Load parameters with US (60 Hz) defaults
1070 12
[Reset modules] Reset all option modules
11001 13
[Read Enc. NP P1] Transfer electronic nameplate motor parameters to the drive from the P1 encoder
11051 14
[Read Enc. NP P2] Transfer electronic nameplate motor parameters to the drive from the P2 encoder
