Table 12-24 Maximum motor cable lengths (400 V drives)
Table 12-25 Maximum motor cable lengths (575 V drives)
Table 12-26 Maximum motor cable lengths (690 V drives)
• Cable lengths in excess of the specified values may be used only
when special techniques are adopted; refer to the supplier of the
drive.
• The default switching frequency is 3 kHz for Open-loop and RFC-A
and 6 kHz for RFC-S mode.
The maximum cable length is reduced from that shown in Table 12-23
and Table 12-24 if high capacitance motor cables are used. For further
information, refer to section 4.9.2 High-capacitance / reduced diameter
cables on page 64.
12.1.24 Minimum resistances and power ratings for
the braking resistor at 40 °C (104 °F)
Table 12-27 Braking resistor resistance and power rating (200 V)
Table 12-28 Braking resistor resistance and power rating (400 V)
400 V Nominal AC supply voltage
Model
Maximum permissible motor cable length for each of
the following switching frequencies
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
03400025 65 m (210 ft)
50 m
(165 ft)
37 m
(120 ft)
03400031 100 m (330 ft)
75 m
(245 ft)
03400045 130 m (425 ft)
100 m
(330 ft)
03400062
200 m (660 ft)
150 m
(490 ft)
03400078
03400100
04400150
200 m (660 ft)
150 m
(490 ft)
100 m
(330 ft)
75 m
(245 ft)
50 m
(165 ft)
37 m
(120 ft)
04400172
05400270
200 m (660 ft)
150 m
(490 ft)
100 m
(330 ft)
75 m
(245 ft)
50 m
(165 ft)
37 m
(120 ft)
05400300
06400350
300 m
(984 ft)
200 m
(660 ft)
150 m
(490 ft)
100 m
(330 ft)
75 m
(245 ft)
50 m
(165 ft)
06400420
06400470
07400660
250 m (820 ft)
185 m
(607 ft)
125 m
(410 ft)
90 m
(295 ft)
07400770
07401000
08401340
250 m (820 ft)
185 m
(607 ft)
125 m
(410 ft)
90 m
(295 ft)
08401570
575 V Nominal AC supply voltage
Model
Maximum permissible motor cable length for each of
the following switching frequencies
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
05500030
05500040
05500069
06500100
300 m
(984 ft)
200 m
(660 ft)
150 m
(490 ft)
100 m
(330 ft)
75 m
(245 ft)
50 m
(165 ft)
06500150
06500190
06500230
06500290
06500350
07500440
07500550
08500630
08500860
690 V Nominal AC supply voltage
Model
Maximum permissible motor cable length for each of
the following switching frequencies
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
07600190
250 m
(820 ft)
185 m
(607 ft)
125 m
(410 ft)
90 m
(295 ft)
07600240
07600290
07600380
07600440
07600540
08600630
250 m
(820 ft)
185 m
(607 ft)
125 m
(410 ft)
90 m
(295 ft)
08600860
Model
Minimum
resistance *
Instantaneous
power rating
Continuous
power rating
Ω kW kW
03200050
20 8.5
1.5
03200066 1.9
03200080 2.8
03200106 3.6
04200137
18 9.4
4.6
04200185 6.3
05200250 16.5 10.3 8.6
06200330
8.6 19.7
12.6
06200440 16.4
07200610
6.1 27.8
20.5
07200750 24.4
07200830 4.5 37.6 32.5
08201160
08201320
Model
Minimum
resistance *
Instantaneous
power rating
Continuous
power rating
Ω kW kW
03400025
74 9.2
1.5
03400031 2.0
03400045 2.8
03400062 4.6
03400078
50 13.6
5.0
03400100 6.6
04400150
34 19.9
9.0
04400172 12.6
05400270 31.5 21.5 16.2
05400300 18 37.5 19.6
06400350
17 39.8
21.6
06400420 25
06400470 32.7
07400660
9.0 75.2
41.6
07400770 50.6
07401000 7.0 96.6 60.1
08401340
08401570
