Unidrive M702 User Guide 29
Issue Number: 3
Figure 3-14 Installation and removal of the KI-Keypad
To install, align the keypad and press gently in the direction shown until it clicks into position.
To remove, reverse the installation instructions.
N
The keypad can be installed / removed while the drive is powered up and running a motor, providing that the drive is not operating in keypad mode.
