Emerson Unidrive M702 User Manual

Safety
information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
Basic
parameters
Running
the motor
Optimization
NV Media Card
Operation
Onboard
PLC
Advanced
parameters
Technical
data
Diagnostics
UL listing
information
12 Unidrive M702 User Guide
Issue Number: 3
The continuous current ratings given are for maximum 40 °C (104 °F), 1000 m altitude and 3.0 kHz switching. Derating is required for higher switching
frequencies, ambient temperature >40 °C (104 °F) and high altitude. For further information, refer to Chapter 12 Technical data on page 227.
Table 2-1 200 V drive ratings (200 V to 240 V ±10 %)
Table 2-2 400 V drive ratings (380 V to 480 V ±10 %)
Model
Normal Duty Heavy Duty
Maximum
continuous
output current
Nominal
power
at 230 V
Motor
power
at 230 V
Peak
current
Maximum
continuous
output current
Open
loop peak
current
RFC peak
current
Nominal
power
at 230 V
Motor
power
at 230 V
AkWhpAAAAkWhp
Frame size 3
03200050 6.6 1.1 1.5 7.2 5 7.5 10 0.75 1
03200066 8 1.5 2 8.8 6.6 9.9 13.2 1.1 1.5
03200080 11 2.2 3 12.1 8 12 16 1.5 2
03200106 12.7 3 3 13.9 10.6 15.9 21.2 2.2 3
Frame size 4
04200137 18 4 5 19.8 13.7 26.2 27.4 3 3
04200185 25 5.5 7.5 27.5 18.5 27.7 37 4 5
Frame size 5 05200250 30 7.5 10 33 25 37.5 50 5.5 7.5
Frame size 6
06200330 50 11 15 55 33 49.5 66 7.5 10
06200440 58 15 20 63.8 44 66 88 11 15
Frame size 7
07200610 75 18.5 25 82.5 61 91.5 122 15 20
07200750 94 22 30 103.4 75 112.5 150 18.5 25
07200830 117 30 40 128.7 83 124.5 166 22 30
Frame size 8
08201160 149 37 50 163.9 116 174 232 30 40
08201320 180 45 60 198 132 192 264 37 50
Model
Normal Duty Heavy Duty
Maximum
continuous
output current
Nominal
power
at 400 V
Motor
power
at 460 V
Peak
current
Maximum
continuous
output current
Open
loop peak
current
RFC peak
current
Nominal
power
at 400 V
Motor
power
at 460 V
AkWhpAAAAkWhp
Frame size 3
03400025 3.4 1.1 1.5 3.7 2.5 3.7 5.0 0.75 1.0
03400031 4.5 1.5 2.0 4.9 3.1 4.6 6.2 1.1 1.5
03400045 6.2 2.2 3.0 6.8 4.5 6.7 9.0 1.5 2.0
03400062 7.7 3.0 5.0 8.4 6.2 9.3 12.4 2.2 3.0
03400078 10.4 4.0 5.0 11.4 7.8 11.7
15.6 3.0 5.0
03400100 12.3 5.5 7.5 13.5 10.0 15.0
20.0 4.0 5.0
Frame size 4
04400150 18.5 7.5 10.0 20.3 15.0 22.5
30.0 5.5 10.0
04400172 24.0 11.0 15.0 26.4 17.2 25.8
34.4 7.5 10.0
Frame size 5
05400270 30.0 15.0 20.0 33.0 27.0 40.5
54.0 11.0 20.0
05400300 31.0 15.0 20.0 34.1 30.0 45.0
60.0 15.0 20.0
Frame size 6
06400350 38.0 18.5 25.0 41.8 35.0 52.5
70.0 15.0 25.0
06400420 48.0 22.0 30.0 52.8 42.0 63.0
84.0 18.5 30.0
06400470 63.0 30.0 40.0 69.3 47.0 70.5
94.0 22.0 30.0
Frame size 7
07400660 79 37 50 86.9 66 99
132 30 50
07400770 94 45 60 103.4 77 115.5
154 37 60
07401000 112 55 75 123.2 100 150
200 45 75
Frame size 8
08401340 155 75 100 170.5 134 201
268 55 100
08401570 184 90 125 202.4 157 235.5
314 75 125
