Description of parameters (FF configuration program) Cerabar S/Deltabar S
24 Endress+Hauser
CLR_FSTATE/
CLEAR FAULT STATE
Selection
Index: 30
Data type: Unsigned8
Access: Auto, OOS
Manually deactivate the fault state of the Discrete Output function block. → See also this
table, SET_FSTATE parameter description.
Possibilities:
• Uninititalized
•Off
• Clear (the fault state is deactivated.)
CONFIRM_TIME
Entry
Index: 33
Data type: Unsigned32
Access: Auto, OOS
Enter the confirmation time for the event report. If the device does not receive any
confirmation within this period, the event report is sent again to the fieldbus host system.
Factory setting:
640000
1
/
32
ms
CYCLE_SEL
Display
Index: 20
Data type: Bit String
Access: Auto, OOS
Displays the block execution method used by the fieldbus host system. The fieldbus host
system selects the block execution method.
Possibilities:
• Scheduled: cyclical block execution method
• Block execution: sequential block execution method
CYCLE_TYPE
Display
Index: 19
Data type: Bit String
Access: Read only
Displays the block execution methods supported by the device. → See also this table,
CYCLE_SEL parameter description.
DD_REV
Display
Index: 13
Data type: Unsigned8
Access: Read only
Displays the revision number of the device description (DD).
DEV_REV
Display
Index: 12
Data type: Unsigned8
Access: Read only
Displays the revision number of the device.
DEV_TYPE
Display
Index: 11
Data type: Unsigned16
Access: Read only
Displays the device identification number.
Deltabar S: hexadecimal: 1009, decimal: 4105.
Cerabar S: hexadecimal: 1007, decimal: 4103.
FAULT_STATE
Display
Index: 28
Data type: Unsigned8
Access: Read only
Current status display of the fault state of the Discrete Output function block.
Possibilities:
• Uninititalized
• Clear (fault state not active)
• Active (fault state active)
FEATURES
Display
Index: 17
Data type: Bit String
Access: Read only
Displays the additional functions supported by the device. → See also this table,
FEATURE_SEL parameter description.
FEATURE_SEL/
FEATURE SELECTION
Selection
Index: 18
Data type: Bit String
Access: Auto, OOS
Select additional device functions. The additional functions the device supports is displayed in
the FEATURES parameter (→ Page 24).
Resource Block
Parameter Description
