Cerabar S/Deltabar S Description of parameters (FF configuration program)
Endress+Hauser 39
PRESSURE_1_UNIT_
TEXT/
CUSTOMER UNIT P
Entry
Index: 41
Data type: Visible String
Access: Auto, OOS
Enter text (unit) for customer-specific pressure unit.
You can enter a maximum of eight alphanumeric characters here. → See also
PRESSURE_1_UNIT_SCALE/CUST. UNIT FACT. P.
Prerequisite:
•CAL_UNIT (→ Page 34) = user unit
!
Note!
Only the first five characters are shown on the on-site display. For example, if "crates" is
specified as the customer-specific unit, "crate" is displayed.
If the unit contains a slash, up to eight characters can be shown on the on-site display. The
maximum number of characters in the counter is again limited to five. For example, if
"crates/m2" is specified as the customer-specific unit, "crate/m2" is displayed. In the FF
configuration program, the slash counts as a character, i.e. "crates/m2" would be displayed as
"crates/m".
Factory setting:
_ _ _ _ _ _ _ _
PRESSURE_1_UNIT_
SCALE/
CUST. UNIT FACT. P.
Entry
Index: 42
Data type: Float
Access: Auto, OOS
Enter conversion factor for a customer-specific pressure unit.
The conversion factor must be entered in relation to the SI unit "Pa".
→ See also PRESSURE_1_UNIT_TEXT/CUSTOMER UNIT P.
Prerequisite:
•CAL_UNIT (→ Page 34) = user unit
Example:
– You want the measured value to be displayed in "PU" (PU: packing unit).
– PRIMARY_VALUE =10000 Pa i 1 PU
– Entry PRESSURE_1_UNIT_TEXT/CUSTOMER UNIT P: PU
– Entry PRESSURE_1_UNIT_SCALE/CUST. UNIT FACT. P: 0.0001
– Result: PRIMARY_VALUE = 1 PU
Factory setting:
1.0
PRESSURE_1_LOWER_
CAL_MEASURED/
LO TRIM MEASURED
Display
Index: 43
Data type: Float
Access: Read only
Displays the pressure that was present at the device during the calibration and which was
used for calibrating the lower point of the response curve. → See also parameter description
for CAL_POINT_LO/LOW SENSOR TRIM (→ Page 34).
PRESSURE_1_UPPER_
CAL_MEASURED/
HI TRIM MEASURED
Display
Index: 44
Data type: Float
Access: Read only
Displays the pressure that was present at the device during the calibration and which was
used for calibrating the upper point of the response curve. → See also parameter description
for CAL_POINT_HI/HIGH SENSOR TRIM (→ Page 33).
