Endress+Hauser cerabar S - Page 69

Cerabar S/Deltabar S Description of parameters (FF configuration program)
Endress+Hauser 69
L_TYPE
Selection
Index: 16
Data type: Unsigned8
Access: OOS
Select linearisation mode for the input value.
Options::
• Direct: in this setting, the input value bypasses the linearisation function and is looped
unchanged with the same unit through the Analog Input Block. If this option is selected,
the scaling and unit for the XD_SCALE and OUT_SCALE parameters must be identical. If
this is not the case, the block changes to the OOS mode and the "Block Config Error" error
is displayed in the BLOCK_ERROR parameter.
• Indirect: the input value is rescaled linearly via the input scaling XD_SCALE to the desired
output range OUT_SCALE.
• Indirect square root: the input value is rescaled by means of the XD_SCALE parameter and
recalculated using a root function. Further rescaling to the desired output range then takes
place via the OUT_SCALE parameter.
Factory setting:
Direct
LO_ALM
Display, Selection
Index: 35
Data type: DS-71
Access: Auto, Man, OOS
Status display for the limit value LO_LIM (→ Page 69).
LO_LIM
Entry
Index: 30
Data type: Float
Access: Auto, Man, OOS
Enter lower limit value.
Input range:
Range and units of OUT_SCALE (→ see Page 71)
Factory setting:
–INF
LO_LO_ALM
Display, Selection
Index: 33
Data type: DS-71
Access: Auto, Man, OOS
Status display for the limit value LO_LO_LIM (→ Page 69).
LO_LO_LIM
Entry
Index: 32
Data type: Float
Access: Auto, Man, OOS
Enter lower critical limit value.
Input range:
Range and units of OUT_SCALE (→ see Page 71)
Factory setting:
–INF
LO_LO_PRI
Entry
Index: 31
Data type: Unsigned8
Access: Auto, Man, OOS
Specify how the system should react if the LO_LO_LIM limit value is undershot (→ Page 69).
Input range:
• 0...15
• 0: The alarm is suppressed.
• 1: The alarm is recognised by the system. There is no notification.
• 2: Reserved for block alarms
• 3...7: Informative alarm with increasing priority,
3: low priority, 7: high priority
• 8...15: Critical alarm with increasing priority,
8: low priority, 15: high priority
Factory setting:
0
Analog Input Block
Parameter Description
