Description of parameters (FF configuration program) Cerabar S/Deltabar S
68 Endress+Hauser
HI_ALM
Display, Selection
Index: 34
Data type: DS-71
Access: Auto, Man, OOS
Status display for the limit value HI_LIM (→ Page 68).
HI_HI_ALM
Display, Selection
Index: 33
Data type: DS-71
Access: Auto, Man, OOS
Status display for the limit value HI_HI_LIM (→ Page 68).
HI_HI_LIM
Entry
Index: 26
Data type: Float
Access: Auto, Man, OOS
Enter upper critical limit value.
Input range:
Range and units of OUT_SCALE (→ see Page 71)
Factory setting:
+INF
HI_HI_PRI
Entry
Index: 25
Data type: Unsigned8
Access: Auto, Man, OOS
Specify how the system should react if the HI_HI_LIM limit value is overshot (→ Page 68 ).
Input range:
• 0...15
• 0: The alarm is suppressed.
• 1: The alarm is recognised by the system. There is no notification.
• 2: Reserved for block alarms
• 3...7: Informative alarm with increasing priority,
3: low priority, 7: high priority
• 8...15: Critical alarm with increasing priority,
8: low priority, 15: high priority
Factory setting:
0
HI_LIM
Entry
Index: 28
Data type: Float
Access: Auto, Man, OOS
Enter upper limit value.
Input range:
Range and units of OUT_SCALE (→ see Page 71)
Factory setting:
+INF
HI_PRI
Entry
Index: 27
Data type: Unsigned8
Access: Auto, Man, OOS
Specify how the system should react if the HI_LIM limit value is overshot
(→ Page 68 ).
Input range:
• 0...15
• 0: The alarm is suppressed.
• 1: The alarm is recognised by the system. There is no notification.
• 2: Reserved for block alarms
• 3...7: Informative alarm with increasing priority,
3: low priority, 7: high priority
• 8...15: Critical alarm with increasing priority,
8: low priority, 15: high priority
Factory setting:
0
IO_OPTS
Selection
Index: 13
Data type: Bit String
Access: OOS
Activate options to process the input and output values of the function block.
Factory setting:
No option activated
Analog Input Block
Parameter Description
