Operation Proline Promass E 300 PROFINET
146 Endress+Hauser
Navigation
"Diagnostics" menu → Measured values → Output values → Value current output 1 to n
‣
Current output 1 to n
Output current 1 to n
→  146
Measured current 1 to n
→  146
Parameter overview with brief description
Parameter Description User interface
Output current 1 Displays the current value currently calculated for the current
output.
3.59 to 22.5 mA
Measured current Displays the current value currently measured for the current
output.
0 to 30 mA
Output values for pulse/frequency/switch output
The Pulse/frequency/switch output 1 to n submenu contains all the parameters needed
to display the current measured values for every pulse/frequency/switch output.
Navigation
"Diagnostics" menu → Measured values → Output values → Pulse/frequency/switch output
1 to n
‣
Pulse/frequency/switch output
1 to n
Output frequency 1 to n
→  146
Pulse output 1 to n
→  146
Switch status 1 to n
→  146
Parameter overview with brief description
Parameter Prerequisite Description User interface
Output frequency 1 to n In the Operating mode parameter, the
Frequency option is selected.
Displays the value currently measured
for the frequency output.
0.0 to 12 500.0 Hz
Pulse output 1 to n The Pulse option is selected in the
Operating mode parameter parameter.
Displays the pulse frequency currently
output.
Positive floating-point
number
Switch status 1 to n The Switch option is selected in the
Operating mode parameter.
Displays the current switch output
status.
• Open
• Closed
Output values for relay output
The Relay output 1 to n submenu contains all the parameters needed to display the
current measured values for every relay output.
