Installation and Operation Manual - COMTEC
®
6000 Dimensional drawings
Doc.-ID: COM6000_11022020_EN 59
Electronics with external pneumatics - SME-50000080
Choke non return valve
A - Reference air
B - Test air
Solenoid valve 3/2 ways
Flow meter
Instrument air in
Test air in
Test gas in
Test gas out
Reference air out
Figure 53 - SME-50000080 gas plan for external pneumatics
