Enotec COMTEC 6000 - Page 60

Dimensional drawings Installation and Operation Manual - COMTEC
®
6000
60 Doc.-ID: COM6000_11022020_EN
Gas plan SME-5 Instrument air (Version A)
Figure 54 - Gas plan (instrument air version A)
Electronic unit Instrument air in (2-10 bar, oil free, dry)
O
2
/CO
e
Probe Test gas 1 in (max. 3 bar)
Flow meter Test gas 2 in (max. 3 bar)
3/2-way solenoid valve (for test gas 2) Test gas out  green tubing (150-180l/h)
3/2-way solenoid valve (for test gas 1)
Reference air out  blue tubing (5-60l/h;
optimal:30-40l/h))
Choke reference air Probe reference air in  blue tubing
Pressure reducer Probe test gas in  green tubing
2
1
3
3
2
6
7
3
98
10
11
12 13
1
2
1
4
5
14
