Name Function
D
[Auto] button
If pressed while projecting analog RGB signals from the
Computer port or the BNC port, you can automatically
optimize Tracking, Sync., and Position.
E
[Test Pattern] button
Displays a test pattern.
s "Displaying a Test Pattern" p.29
F
[Lens Shift] button
Press to adjust the lens shift.
s "Adjusting the Position of the Projected Image (Lens
Shift)" p.31
If pressed for more than five seconds, the lens position
moves to the home position.
G
[Zoom] button
Press to adjust the zoom.
s "Adjusting the Image Size" p.33
H
[Focus/Distortion]
button
Press this to adjust the focus or correct distortion.
s "Correcting the Focus" p.34
s
"Correcting Distortion (Image Warping)" p.34
I
[Geometry] button
Corrects distortion in the projected image.
s "Correcting Distortion in the Projected Image"
p.55
J
[Shutter] button
Press to turn the image on or off temporarily.
s "Hiding the Image Temporarily (Shutter)" p.100
K
[ ] button
When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
s "Using the Configuration Menu" p.116
L
[ ][ ][ ][ ]
buttons
• Press to adjust focus, zoom, and lens shift.
s "Adjusting the Position of the Projected Image
(Lens Shift)" p.31
s "Adjusting the Image Size" p.33
s "Correcting the Focus" p.34
• If pressed when the Configuration menu or the Help
screen is displayed, menu items and setting values are
selected.
s "Using the Configuration Menu" p.116
Name Function
M
[ ] button
Displays the Control Panel Lock screen allowing you to
make settings to lock the control panel buttons.
s "Restricting Operation" p.111
N
[ ] button
Press to turn on or off the buttons on the control panel and
the status monitor.
O
[Esc] button
• Stops the current function.
• If pressed when the Configuration menu is displayed, it
returns to the previous menu level.
s "Using the Configuration Menu" p.116
P
[ ][ ][ ][ ]
buttons
Press to select the menu items and setting values for status
monitor to monitor the projector's status.
Q
Status monitor
Displays the projector's status by character information.
s "Reading Status Monitor" p.154
R
[Menu] button
Displays and closes the Configuration menu.
s "Using the Configuration Menu" p.116
Part Names and Functions
18
