When using the ELPLW07/ELPLM12/ELPLM13/ELPLM14
A
Center of lens
B
Projected image when the lens position is moved to the home
position
C
Maximum motion range: V x 65%
*
* When performing screen matching: V x 60% (ELPLM13)
* When the horizontal direction is at the maximum value, the image
cannot be moved vertically.
a
• When adjusting the image height with the vertical lens shift, adjust
by moving the image from the bottom to the top. If it is adjusted
from the top to the bottom, the image position may move down
slightly after adjusting.
• We recommend setting the focus, zoom, and lens shift at least
20 minutes after you start the projection, because images are not
stable right after turning on the projector.
• The image will be clearest when the lens position is moved to the
home position.
• If you hold down the [Lens Shift] button on the remote control or
the control panel for at least three seconds, the lens position moves
to the home position.
• If you set A/V Output to Always On, you can move the lens
position to the home position even if the projector is in standby
mode.
s
Extended - A/V Settings - A/V Output p.125
a
Press the [Lens Shift] button on the remote control or the control
panel.
Using the remote control Using the control panel
Installing the Projector
32
