Boundary lines that indicate areas where images overlap are
displayed.
The boundary lines are displayed based on the settings for Top
Edge/Bottom Edge/Right Edge/Left Edge.
c
Use the [ ][ ][ ][ ] buttons to select a boundary line of the
area you want to adjust.
The selected line is displayed in orange.
d
Press the [ ] button to confirm the selection.
The points where you want to set the range for adjustment are
displayed.
You can change the number of points displayed on one side in
Points on the screen from step 8.
e
Use the [ ][ ][ ][ ] buttons to adjust the boundary line
positions, and then press the [
] button.
f
Press the [ ][ ][ ][ ] buttons to select the point you want to
move, and then press the [
] button.
The selected point is displayed in orange.
g
Press the [ ][ ][ ][ ] buttons to move the point.
Multi-Projection Function
91
