Epson EH-TW5300 User Manual

Contents
3
Organization of the Guide and
Notations in the Guide
Using Each Guide ..................... 1
Notations Used in This Guide ........... 2
Safety Indications.......................2
General Information Indications .............2
About the Use of "This Product" or "This Projector" 2
Introduction
Projector Features .................... 6
Dynamic 3D Display ...................... 6
Project Images from Mobile Devices ..........6
Quick and Easy to Install, Use, and Remove.....6
Quick Image Adjustments .................6
Other Useful Functions .................... 6
Part Names and Functions ............. 8
Front/Top ............................. 8
Control Panel .......................... 9
Remote Control ........................ 11
Rear ................................ 13
Base ................................ 13
Preparing
Installing ............................ 15
Projected Image and Position of Projector.....15
Installing in parallel with the screen ........ 15
Installing the projector horizontally by
adjusting the height of either side ......... 15
Various Setting Methods.................16
Placing on a table and projecting.........16
Suspending from the ceiling and projecting . . 16
Adjusting the Projection Size..............17
Connecting a Device ................. 19
Connecting Video Equipment ..............19
Connecting a Computer .................. 19
Connecting Smartphones or Tablets .........20
Connecting USB Devices .................. 20
Connecting External Speakers .............. 21
Connecting Bluetooth
®
Devices ............ 21
Preparing the Remote Control ........ 24
Installing the Remote Control Batteries.......24
Remote Control Operating Range ...........25
Operating range (left to right) ............ 25
Operating range (top to bottom) .......... 25
Basic Operations
Projecting Images ................... 26
Turning On the Projector.................26
If the target image is not projected . . . . . . . . 26
Using the Home Screen .................. 27
Turning Off ...........................28
Adjusting the Projected Image . . . . . . . . 29
Displaying the Test Pattern ................ 29
Adjusting the Focus ..................... 29
Adjusting the Projection Size ..............29
Adjust the Height of the Image .............29
Adjusting the Projector's Tilt ...............30
Correcting Distortion .................... 30
Correct automatically (Auto V-Keystone)
(EH-TW5350/EH-TW5300 only)...........30
Correct manually (H-Keystone adjuster) . . . . . 31
Correct manually (H/V-Keystone) .......... 31
Adjusting the Volume .................... 32
Hiding the Image and Muting the Audio
Temporarily (A/V Mute) .................. 32
Adjusting the Image
Adjusting the Image ................. 33
Selecting the Projection Quality (Color Mode) . . 33
Switching the Screen Between Full and Zoom
(Aspect)............................. 34
Adjusting the Sharpness .................. 35
Adjusting Image Resolution (Image
Enhancement) ......................... 35
Setting Auto Iris ........................ 36
Setting Frame Interpolation...............36
Adjusting the Color .................. 37
Adjusting the Color Temp.................37
Adjusting the RGB (Offset and Gain).........37
Adjusting Hue, Saturation, and Brightness . . . . . 37

Epson EH-TW5300 Specifications

General

Contrast Ratio	35, 000:1
Projection Technology	3LCD
Weight	3.5 kg
Resolution	1920x1080 (Full HD)
Keystone Correction	Vertical ±30 degrees
Inputs	2 x HDMI, 1 x VGA, 1 x USB Type A, 1 x USB Type B
Speaker	5W
Throw Ratio	1.22 - 1.47
Projection Size	34 inches - 328 inches
Brightness	2, 200 lumens
