4-28
EMP-TW1000
SEIKO EPSON Revision:A
C A U T I O N
 Attach EMI Suppressors and heat-resistant tape on the bottom of the MA
board following the instructions below.
1). Attach the EMI Suppressor; D on the area (1) while aligning it along the
standard line (A) as shown in Figure 4-25.
2). Attach the EMI Suppressor; E on the area (2) while aligning it along the
standard line (B) as shown in Figure 4-25.
3). Attach heat-resistant tape on the area (3) as shown in Figure 4-25. Do not
cover the electrolytic condenser with the tape when attaching it.
Figure 4-25.
EMI Suppressor; D
EMI Suppressor; E
heat-resistant tape
electrolytic condenser
standard line (A)
standard line (B)
(1)
(2)
(3)
