Epson EMP-TW1000 - REMOVING MOTOR CF ASSY., CF SW ASSY., MICRO SW ASSY., ML FASTEN SPRING, FRAME CF ASSY., AND AUTO IRIS ASSY.; REMOVING MOTOR CF ASSY., CF SW ASSY., MICRO SW ASSY., ML FASTEN SPRING, FRAME CF ASSY., AND AUTO IRIS ASSY. (CONTINUED)

4-32
EMP-TW1000
SEIKO EPSON Revision:A
C A U T I O N
 Secure the CF Motor Cable and Auto Iris Sensor Cable with heat-resistant tape
as shown in Figure 4-30.
Figure 4-30.
heat-resistant tape
CF Motor Cable
Auto Iris Sensor Cable
