Settings item Settings value Explanation
Page Margin
3 mm
*
Select the top, bottom, left, and right margin values.
For a cut sheet, the top, bottom, left, and right margin values are 3
mm regardless of the settings.
5 mm
Smoothing On This setting is enabled when Resolution is set to Standard, and
resolution not specied in the sent print data. Setting this to On
prints at the maximum resolution corresponding to that paper's
Paper Type settings selected in Paper Source, but depending on
the data, this may result in a long print time, or failures in printing
because of insucient memory.
O
*
Base Output Size
Auto
*
The hard clip area of the PS command of the data becomes the
base output size. The actual output size depends on the Page
Margins option. When the data does not contain a PS command,
the smallest rectangle area
of in the following illustration
including the print object becomes the base output size.
A Series The compatible standard sizes for the selected Paper Source are
displayed, therefore select the Base Output Size. The actual output
size depends on the Page Margins option.
For a cut sheet, this setting is available only when the data does not
contain a PS command. If the data contains a PS command, this
setting is not available, and the hard clip area of the PS command
becomes the Base Output Size.
US-ANSI
US-ARCH
B Series (ISO)
B Series (JIS)
Others
User-Dened Select this option when outputting at non-standard sizes. After
selecting this setting, set Paper Width and Paper Height. You can
set in 0.1 mm increments.
The actual output size depends on the Page Margins option.
SC-T5100 Series/SC-T3100 Series/SC-T5100N Series/SC-T3100N Series User's Guide
Using the Menu
122
