EPSON Stylus Color 980 Revision A

Adjustment Adjustments 141

5.2.7 USB ID Retrieval

This section describes the procedure of USB ID retrieval.

1. Perform the operation of USB ID Input (5.2.6) 1-3.

2. Select “Check USB ID”.

3. Click “OK”.

4. The following screen appears.

Figure 5-16. Check USB ID Screen
