Epson Stylus Color 980 Service Manual

EPSON Stylus Color 980 Revision A
Adjustment Adjustments 142
5.2.8 Printhead Cleaning Using the Program
The service program for the Stylus Color 980 has the cleaning function.
The command is always executed with the most powerful cleaning
mode. Note the printer is not equipped with the dummy cleaning called
CL3. Therefore, you can attempt to solve the nozzle clogging problem
by pressing the Cleaning button on the control panel repeatedly.
1. Referring to Section 5.2.1, perform the preliminary operation.
2. Select “Maintenance items” from the main adjustment menu.
3. Select “Head Cleaning”.
4. The following screen appears.
Figure 5-17. Main maintenance Menu Screen
5. Click “OK”.
6. The following screen appears.
Figure 5-18. Cleaning Screen
7. Head cleaning is start.
