Epson Stylus Color 980 Service Manual

EPSON Stylus Color 980 Revision A
Appendix EEPROM ADDRESS MAP 165
7.2 EEPROM ADDRESS MAP
This section contains the EEPROM map for the Stylus Color 980.
Table 7-13. EEPROM Address Map (1/8)
*1: See NOTE at the end of the section.
Table 7-14. EEPROM Address Map (2/8)
*1, *2: See NOTE at the end of the section.
Address Explanation Settings
QPIT
settings
Factory
settings
00H Password 0 0FH
−
01H 5AH
−
02H EEPROM mapping revision 41H
−
03H reserved 00H
−
04H CG
0: STD
1: NLSP
00H (*1)
05H Market ID
0: Standard
(World)
1: Custom
00H (*1)
06H, 07H,
08H, 09H
Custom EEPROM sub number 00H 00H
0AH Head actuator rank ID for VhN 00H (*1)
0BH reserved 00H
−
0CH reserved 00H
−
0DH Head actuator rank ID for VhL 00H (*1)
0EH Head actuator rank ID for VhU 00H (*1)
0FH Head actuator rank ID for VhM 00H (*1)
10H reserved for Head-ID 00H (*1)
11H reserved for MicroWeave-ID 00H (*1)
12H Head actuator rank ID for lwC 00H (*1)
13H Head actuator rank ID for IwM 00H (*1)
14H reserved 00H
−
Address Explanation Settings
QPIT
settings
Factory
settings
15H Bi-D Adjustment data
(for Normal x3)
-36 <= n <= +36
(by 1/1440 inch)
00H (*1)
16H Bi-D Adjustment data
(for Variable-2)
-36 <= n <= +36
(by 1/1440 inch)
00H (*1)
17H Bi-D Adjustment data
(for Variable-1)
-36 <= n <= +36
(by 1/1440 inch)
00H (*1)
18H Uni-D Adjustment data -36 <= n <= +36
(by 1/1440 inch)
00H (*1)
19H reserved 00H
−
1AH reserved 00H
−
1BH 1st dot position adjustment
data
00H (*1)
1CH reserved 00H
−
1DH reserved 00H
−
1EH reserved 00H
−
1FH ERROR Code 00H 00H
20H, 21H,
22H, 23H
CPSI password 00H 00H
24H CPSI license flag
0: disable
1: enable
00H 00H
25H CPSI font license
0: disable
1: enable
00H 00H
26H Interface selection
0: Auto
1: Parallel
2: Serial
3: USB
4: Option
00H 00H (*2)
