Epson Stylus Color 980 Service Manual

EPSON Stylus Color 980 Revision A
Appendix EEPROM ADDRESS MAP 166
Table 7-15. EEPROM Address Map (3/8)
*2: See NOTE at the end of the section.
Table 7-16. EEPROM Address Map (4/8)
Address Explanation Settings
QPIT
settings
Factory
settings
27H Interface time-out 0 to 255
(by second, value of 0
means 10 seconds)
0AH 0AH
28H Compatibility speed
0: Fast
1: Slow
2: Special-1
3: Special-2
00H 00H
29H ECP speed (*A)
*A: BUSY signal delay time from fall-edge of a -STB signal. (Fast: Max. 1MB/s,
Slow: Max. 600KB/s)
0: Fast
1: Slow
00H 00H
2AH IEEE1284.4 for
Parallel
0: Auto
1: On
2: Off
00H 00H
2BH I/F Control flags bit1: ECP mode
(0=Off, 1=On) (*B)
bit0: lEEE1284 mode
(0=On, 1=Off) (*C)
*B: Selects IEEE1284 transfer mode. (ECP pr Nibble)
*C: Enables or disables reverse transfer. (When disabled, ignore -SLN signal.)
00H 00H
2CH IEEE1284.4 for USB
0: Auto
1: On
2: Off
00H 01H
2DH, 2EH,
2FH
reserved for USB 00H
−
Address
Explanati
on
Settings
QPIT
settings
Factory
settings
30H Font
0: Roman
2: Courier
4: Script
11: Sans Serif H
1: Sans Serif
3: Prestige
10: Roman T
7: Draft
00H 02H
31H Pitch
0: 10cpi
2: 15cpi
4: 20cpi
1: 12cpi
3: 17cpi
5: Proportional
00H 00H
32H Print
direction
control
0: Bi-D
1: Uni-D
2: Auto
02H 02H
33H CG table
0: Italic U.S.A
2: Italic Germany
4: Italic Denmark
6: Italic Italy
8: PC 437
10: PC 850
12: PC 863
14: PC 861
16: Abicomp
18: lSO Latin1
20: PC 855
22: PC 857
24: PC 869
26: Code MJK
28: lSO Latin 1T
30: PC 774
32: ISO 8859-2
34: PC 866UKR
36: PC APTEC
38: PC 720
40: Hebrew8
42: PC 858
1: Italic France
3: Italic U.K
5: Italic Sweden
7: Italic Spain
9: PC 437 Greek
11: PC 860
13: PC 865
15: BRASClI
17: Roman 8
19: PC 853
21: PC 852
23: PC 866
25: MAZOWIA
27: ISO 8859-7
29: Bulgaria
31: Estonia
33: PC 866 LAT
35: PC AR864
37: PC 708
39: Hebrew7
41: PC 862
43: ISO 8859-15
08H 08H
