EPSON Stylus Color 980 Revision A
Adjustment Adjustments 149
22. Holding the right parallelism adjustment bushing with your hand so it
does not move, fasten the screw.
23. Holding the left parallelism adjustment bushing with your hand so it
does not move, fasten the screw.
24. Remove the thickness gauge.
25. If the linear scale is dislocated, set it through the photo sensor at the
back of the carriage.
26. Move the carriage to the right.
27. Install the upper case.
