Epson Stylus Color 980 Service Manual

EPSON Stylus Color 980 Revision A
Appendix EEPROM ADDRESS MAP 168
Table 7-19. EEPROM Address Map (7/8)
*2, *3: See NOTE at the end of the section.
Table 7-20. EEPROM Address Map (8/8)
NOTE:
*1: Adjusted at factory.
*2: Initialized after panel initialization is performed.
*3: Initialized after initialization of the ink overflow counter in EEPROM is performed.
Address Explanation Settings
QPIT
settings
Factory
settings
5EH, 5FH Ink counter Ry0 00H 00H
60H, 61H Ink counter A0 00H 00H (*3)
62H, 63H Power off time 00H 00H (*2)
64H, 65H CL time 00H 00H (*2)
66H, 67H accumulated printing
time
00H 00H
68H, 69H reserved for ink-
system
00H
−
6AH, 6BH,
6CH, 6DH,
6EH, 6FH,
70H, 71H,
72H, 73H,
74H, 75H,
76H, 77H,
78H, 79H,
7AH, 7BH,
7CH, 7DH,
7EH, 7FH
Printer-ID Strings[22] 00H 00H
80H Password 2 0FH
−
81H 5AH
−
82H Ink end by Head
temperature
00H 00H
83H P2 00H 00H
84H P1 00H 00H
85H Temperature at Bi-D
adjustment (refer to
EEPROM 15H)
00H 00H
Address Explanation Settings
QPIT
settings
Factory
settings
86H Temperature at Bi-D
adjustment (refer to
EEPROM 16H)
00H
−
87H Temperature at Bi-D
adjustment (refer to
EEPROM 17H)
00H
−
88H reserved 00H
−
89H reserved 00H
−
8AH Head TG-ID 0: Sharp 1: SEC 00H (*1)
8BH reserved 00H
−
8CH, 8DH,
8EH, 8FH
Total count of Paper
through
00H 00H
90H, 91H Ink counter Rb80 00H 00H
92H, 93H Ink counter Ry80 00H 00H
94H, 95H Ink counter A80 00H 00H
96H, 97H,
98H, 99H
Total count of CR
seek
00H 00H
9AH, 9BH,
9CH, 9DH,
9EH, 9FH
reserved 00H
−
