Epson Stylus Color 980 Service Manual

EPSON Stylus Color 980 Revision A
Appendix Parts List 175
Table 7-25. Parts List (5/6) Table 7-26. Parts List (6/6)
No. Description No. Description
612 LEVER, CHANGE 637 HOLDER, SHEET, PAPERFEED
613 COMBINATION GEAR, 14.4, 24 638 ROLLER ASSY, LD, LEFT
614 SPUR GEAR, 20.8 639 ROLLER ASSY, LD, RIGHT
615 COMBINATION GEAR, 12.8,
27.2
640 COVER, ROLLER, LD, LEFT
616 COMBINATION GEAR, 20, 38.4 641 COVER, ROLLER, LD, RIGHT
617 SPUR GEAR, 26.25 642 COMPRESSION SPRING, 1.961
620 FRAME, ASF 643 PAPER LOADING ASSY., RIGHT
621 WHEEL, DETECT 644 PAPER LOADING ASSY., LEFT
622 LEVER, FASTEN,
EDGEGUIDE;B
647 FERRITE CORE
623 EXTENSION SPRING, 0.088 658 SPUR GEAR, 27.2
624 SHAFT, ROLLER, LD 659 HARNESS, ASF
625 LEVER, HOPPER, RELEASE 663 C.B.P-TITE(P4), 3X8, F/ZN
626 HOPPER 664 C.P.SCREW, M3X3
627 REINFORCEMENT PLATE,
HOPPER
665 C.B.P-TITE SCREW, 3X6, F/ZN
628 EDGE GUIDE; D 666 C.P.P-TITE SCREW, 4X12, F/ZN
629 SLIDER, EDGEGUIDE 667 C.B.P-TITE, 2.5X5, F/ZN
630 COMPRESSION SPRING, 3.23 668 C.B.S. SCREW
631 PAD, BREAK, EDGE GUIDE 669 RETAINING RING
632 CORK 670 RETAINING RING
633 CORK;B 671 RETAINING RING
634 SHAFT, MOUNT, CR 672 PLAIN WASHER 6.1X0.5X12, F/NI
635 C.P.S-TITE(P4), 3X6, F/ZN 673 PLANE WASHER, 12.2X0.5X15
636 SHEET, PAPERFEED 674 PLAIE WASHER
No. Description No. Description
675 PLANE WASHER 721 EXTENSION SPRING, 0. 62
676 LEAF SPRING 722 LEVER, PAPERRETURN, RIGHT
677 LEAF SPRING 723 EXTENSION SPRING, 0. 294
678 U-TYPE S.W. 724 ROLLER, LD, SUPPORT
679 FERRITE, CLAMP 725 HOLDER, ROLLER, LD,
SUPPORT, RIGHT
680 SHEET, PRESSING PLATE, HP 726 PAD ASSY., LEFT
681 GUIDE, PAPER EJ. 727 LEVER, PAD, RELEASE, LEFT
682 CLAMP, FERRITE CORE 728 HOLDER, EDGEGUIDE, LEFT
683 SPACER, FRAME, IS 729 LEVER, PAPERRETURN, LEFT
685 CLAMP, CABLE 730 HOLDER, ROLLER, LD,
SUPPORT, LEFT
700 PRINT HEAD, IJ480-0AA 800 ASF UNIT
716 PAD ASSY., RIGHT 3 PAD PRINTER
717 LEVER, PAD, RELEASE, RIGHT 4 PAD, ACCESSORY
718 PAD SRRING, HOLDER, PAD 5 PAD, STACKER
719 HOLDER, EDGEGUIDE, RIGHT 6 RLASTIC PROTECTIVE BAG,
510X870X0.05T
720 COMPRESSION SPRING, 1. 17 7 PAD, ASF
