Stylus Pro 4880 Field Repair Guide 1/17/08
Connectors / Wiring Printer Component, Software Item, LCD Display, Printer Button Page 197.
Connectors / Wiring
Main Board Connectors
Connector #: Connected To: Pins:
CN1 Power Supply CN2 14
CN7 Carriage Board (C593 Sub Board D) CN1 31
CN8 Carriage Board (C593 Sub Board D) CN2 31
CN9 Carriage Board (C593 Sub Board D) CN3 30
CN12 USB 2.0 4
CN14 Paper Feed Motor 3
CN15 Carriage Motor 3
CN16 ASF/Pump Motor 4
CN18 Platen Gap Motor 4
CN19 Vacuum Fan #1 (Right Side) 2
CN20 Vacuum Fan #2 (Left Side) 2
CN23 Sub Board C CN 1 26
CN48 C 511Sub Board B CN102 17
CN50 Head Driver Cooling Fan 2
CN51 C 511Sub Board B CN101 30
CN52 C593 Sub Board C CN200 15
CN53 C593 Sub Board C CN201 28
