Stylus Pro 4880 Field Repair Guide 1/17/08
Damper Removal Printer Component, Software Item, LCD Display, Printer Button Page 46.
Damper Removal
1. Raise both Ink Levers, closing the Ink Valves.
2. Remove the Left Side Cover.
3. Move the Carriage Mechanism to the left as shown, remove 3 Screws, and remove the Carriage
Cover.
3 Screws
Slot
Lift off
