Epson Stylus Pro 4880 - Sensors, Motors, Solenoids, and Fans

Stylus Pro 4880 Field Repair Guide 1/17/08
Sensors, Motors, Solenoids, and Fans Printer Component, Software Item, LCD Display, Printer Button Page 217.
Sensors, Motors, Solenoids, and Fans
1.
Home Position Sensors: Carriage HP Sensor (CR Origin)
Gap HP Sensor (Head Slide)
Pump HP Sensor(Pump)
Exit Roller HP Sensor (POUT)
ASF Roller HP Sensor
Maintenance/Waste Ink Tank Sensor Waste Ink ID (CSIC) (MainteTank)
Ink Cartridge Sensors: Cartridge CSIC’s (Customer Satisfaction Ink Cartridge
(8)
Ink Cartridge Lock Lever Sensor (2)(Ink Lever)
Encoders: Carriage Encoder
Paper Feed Encoder
Paper Sensors: Manual Feed Sensor (Rear Det)
Paper Empty Sensor (RearAD)
Multi Sensor (EdgeAD) (Edge2AD)(Width, Leading
Edge, Nozzles, Alignments)
Paper Thickness Sensor (Paper)(Lever)(also registers
paper release)(2 Sensors)
ASF Input Sensor (P Det)
Safety Sensors: Top Cover Sensor(Cover)
Rear Cover Sensor(Rear Guide)
Exit Roller Customer Safety Sensor
Temperature Sensors: Head Temperature Sensor (Head Temp)
Head Driver Temperature Sensor (Drv Temp)
