Stylus Pro 4880 Field Repair Guide 1/17/08
Connectors / Wiring Printer Component, Software Item, LCD Display, Printer Button Page 200.
C593 Sub Board D
C593 Carriage Board
Power Supply
Connector #: Connected To: Pins:
CN1 Main Board CN7 31
CN2 Main Board CN8 31
CN3 Main Board CN9 31
CN4 Carriage Board CN1 24
CN5 Print Head 31
CN6 Print Head 31
Connector #: Connected To: Pins:
CN1 Sub Board D CN4 24
CN2 Cutter Solenoid 2
CN3 Multi Sensor 5
CN4 Carriage Encoder 5
Connector #: Connected To: Pins:
CN1 AC Power 2
CN2 Main Board CN1 14
