Epson Stylus Scan 2000 - Page 139

EPSON Stylus Scan 2000
Revision A
Maintenance
Lubrication
138
Figure 6-4. #2 Front Paper Guide - C
Figure 6-5. #3 Carriage Assembly Contact Point
Figure 6-6. #4 Combination Gears and #5 Gear Shaft
G-26
270 mm (between the screw and indent)
G-26
Indent
Screw
No. 5
No. 4
"GEAR, 23.2"
"GEAR, 16,
40.8"
No.4
"GEAR, 73.6"
No.4
"COMBINATION
GEAR,8 14.4"
