5.3.8 Ink draining
To drain the ink from the cartridge before transporting it a long distance, follow the steps
below.
1. Enter the Production menu as described in “Using the Service-Adjustment
Program” on page121.
2. On the Production menu (Figure 5-6), select Ink Discharge. Click OK in
the following dialog box.
SPECIAL MENU
To enter the Special menu, follow these steps.
1. Open the Start-up menu as described on page121.
2. Double-click Special and click OK.
3. Double-click Counter Clear and clice OK.
5.4 Scanner Adjustment
The scanner mechanism requires no adjustment for any service operation provided you
closely follow the specifications in this manual and the instructions in Chapter 4
“Disassembly and Assembly”.
You can also perform a hex dump of the EEPROM data by double-
clicking EEPROM DUMP on the Special menu. The printer will
print the EEPROM parameters in hexadecimal characters.
