EPSON Stylus Scan 2000
Revision A
Maintenance
Lubrication
142
6.3.1.1 Scanner Mechanism
This chapter provides information necessary to keep the scanner function in optimum
condition constantly and to prevent troubles.
When the carriage unit needs to be replaced, or the operation sound of the carriage
movement becomes noisy, it is necessary to apply lubrication. Following tables show the
recommended grease type and lubrication points.
Note*) ā€œEā€ means exclusive product for EPSON. (Not available on the market.)
Table 6-3. Recommended Grease
Type Name
Supply
Quantity
Part No. Specification
Grease G-26 40g B702600001 E*
Table 6-4. Lubrication points
Figure Lubrication Points Lubrication
6-1
Transmission Gear Shaft of the CR motor and Driven
pulley shaft.
G-26 (1x3mm)
6-1 Driven Pulley Shaft G-26(1x3mm)
Excessive lubrication may damage the mechanism part or cause the
malfunction of the operation.
