Epson Stylus Scan 2000 Service Manual

Stylus Scan 2000
Revision A
Appendix
Connector Summary
148
Table 7-11. Connector Pin Assignment-CN12
Pin No. Signal Name I/O Function
1 SPWR O
2 GMD O
3 SENSE I
Table 7-12. Connector Pin Assignment-CN13
Pin No. Signal Name I/O Function
1 A O
2 Ax O
3 B O
4 Bx O
5 COM1 O Head drive power supply (1)
6 COM2 O Head drive power supply (2)
Table 7-13. Connector Pin Assignment-CN14
Pin No. Signal Name I/O Function
1 VOR I
2 AGND O
3 VOG I
4 AGND O
5 VOB I
6 AGND O
7 12VC O
8 PH1 O
9 PH2 O
10 SH O
11 DGND O
12 RS O
13 CP O
14 VCC O
Table 7-13. Connector Pin Assignment-CN14
Pin No. Signal Name I/O Function
