Epson Stylus Scan 2000 Service Manual

Stylus Scan 2000
Revision A
Appendix
Parts List (update is coming)
159
7.4 Parts List (update is coming)
Table 7-15. Parts List (1/4)
100
Housing;B
128
Mini Clamp
101
Cover, Printer;B
180
Label, Caution 1;B
102
Paper Support;B
181
Label, Accessory B
103
Stacker Assembly;B
182
Label, Accessry C
104
Panel Assembly, Right;B
183
Label, Lever Cartridge, Black
105
Shield Plate, Panel
184
Label, Lever Cartridge, Color
106
Housing, Panel, Left;B
200
Board Assembly, Main
107
Button, P/S;B
300
Board Assembly, Power Supply
108
Groundign Plate
330
Harness
109
Cover, Shield Plate, M/B, Right
400
Power Cable Assembly
110
Cover, Shield Plate, M/B, Left
450
Board Assembly, Panel
111
Cover, Cable
500
Printer Mechanism
112
Cover, Inlet, Upper;B
501
Frame Assembly, Left
113
Cover, Inlet, Lower;B
502
Motor Assembly, PF
114
Shiled Plate, M/B;C
503
Spur Gear, 23.2
115
Logo Plate
504
Combination Gear, 16, 40.8
116
Housing, Sub, Right;B
505
Frame, Right
117
Housing Sub, Left;B
506
Frame, Top
119
Foot
507
Motor Assembly, CR
121
CP Screw, M3x6
508
Pump Assembly
122
CBS-Tite Screw, M3x6
509
Cap Assembly
123
CB(O) Screw, 4x5, F/Zg
510
Frame, Bottom
124
CBS-Tite Screw, M3x10
511
Sheet, Protection, Head
125
CBP-Tite Screw, M3x8, F/Zn
512
Frame, Front
126
CBP-Tite Screw, M3x10, F/Zn
513
Bushing, Parallelism Adjustment, Left
