Epson Stylus Scan 2000 Service Manual

Stylus Scan 2000
Revision A
Appendix
Parts List (update is coming)
160
Table 7-16. Part List (2/4)
514
Bushing, Parallelism Adjustment,
Right
546 Paper Guide, Right
515
Paper Guide, Rear 547 Paper Guide, Left
516
Roller, PF 548 Shaft, Paper Guide, Upper
517
Compression Spring, 5.85 549 Shaft, Roller, Driven
518
Bushing, 12, Left 550 Roller, Driven;D
519
Lever, Change 551 Torsion Spring, 117.6
520
Spur Gear, 26.4 552 Board Assembly, PE
521
Spacer, C-ring 553 Holder, PE
522
Scallop Sp-AW, 2x16, F/B 554 Lever, PE
523
Compression Spring, 0.9 555 Torsion Spring, 0.22
524
Spur Gear, 73.6 556 Sheet, Guide Plate, Cable
525
Spacer, Fixing, Roller, PF 557 Guide Plate, Cable
526
Spacer, Fixing, Roller, PF;B 558 Sheet, Cable
527
Crescent Ring 559 Detector, PE
528
Plain Washer12.2x0.5x15 560 Carriage Assembly
529
Roller Assembly, Paper Eject 561 Lever, Adjust
530
Bushing, 6 562 Grouding Plate, Head
531
Retaining Ring, Type-E(4) 563 Oil Pad
532
Spur Gear, 36 564 Slider, CR
533
Spur Gear, 11 565 Timing Belt
534
Plain Washer, 4.1x0.5x6.5 566 Shaft, CR, Guide
535
Paper Guide, Front 567 Pulley Assembly, Driven
536
Grounding Spring, Paper Eject 568 Holder, Pulley, Driven
538
Frame, Paper Eject 569 Compression Spring, 19.6
539
Holder, Star Wheel, Right 570 Lever, PG
540
Holder, Star Wheel, Left 571 Lever, PG, Sub
541
Holder, Star Wheel, Front 572 Torsion Spring, 63.7
542
Star Wheel Assembly, 8(Natural) 573 Combination Spring, 6, 34.4
543
Star Wheel 8;B 574 Combination Spring, 8, 30
544
Bar Spring, Star Wheel 576 Absorber, Slider, Cap
545 Paper Guide, Upper 577 Bushing, Fixing, Combination Gear
Table 7-16. Part List (2/4)
