Printing is not performed.
The carriage moves, but
no printing is performed.
Head FFC is out of
connection.
Check if the head FFC on the board or carriage
is connected surely.
Connect the FFC properly.
The FFC is disconnected
inside.
Check the FFC by using a tester. Replace the FFC.
I/C is defective. Install a new I/C and perform the self-test. Replace I/C.
Head unit is defective.
If the condition does not improve even after 2or
3 times cleaning operation, replace the head
unit and perform the self-test.
Replace the head unit.
Table 3-3. Repair of the Printer Mechanism (continued)
Symptom Condition Cause Check Point Solution
