Rev.D Parts List Appendix E-11
TM-U675/U675P (with autocutter) Service Manual
Confidential
Support plate PLATE,SUPPORT,A 1 F-1 137
Table holder HOLDER,TABLE,A 1 F-1 138
Operation label (type FA) LABEL,OPERATION,FA 1 F-1 139
Operation label (type BA) LABEL,OPERATION,BA 1 F-1 140
Holder plate (type A) PLATE,HOLDER,A 1 F-1 141
Holder spring SPRING,HOLDER,A 1 F-1 142
Roll paper holder HOLDER,ROLL PAPER,A 1 F-1 143
Front sound absorption material SOUND ABSORPTION MATERIAL,FRONT 2 F-1 144
Take-up gear GEAR,TAKE-UP 1 F-1 146
Take-up frame assembly FRAME,TAKE-UP ASSEMBLY 1 F-1 147
Front seal SEAL,FRONT,AA 1 F-1 148
Operation label (type DA) LABEL,OPERATION,DA 1 F-1 149
Take-up spring TAKE UP SPRING 1 F-1 151
Take-up pulley TAKE UP PULLEY 1 F-1 152
Paper take-up belt PAPER TAKE UP BELT 1 F-1 153
Roll paper receive roller ROLL PAPER RECEIVE ROLLER 3 F-1 154
Hexagon lock screw (inch type) HEXAGON LOCK SCREW 2 F-1 155
Screw (C.P.S-tite, 3X6) C.P.S-TITE SCREW,3X6,F/ZN - F-1 155
Power switch cover COVER,POWER SWITCH,BA 1 F-1 156
Control panel label LABEL,SWITCH PANEL,AA 1 F-1 157
Operation label (type EA) LABEL,OPERATION,EA 1 F-1 158
Roll paper guide GUIDE,ROLL PAPER 1 F-1 159
Holder plate (type B) PLATE,HOLDER,B 1 F-1 160
76 mm kit 76MM KIT 1 F-1 161
Head caution seal SEAL,CAUTION,HEAD B 1 F-1 162
E-ring (3) RETAINING RING, TYPE-E(3) - F-2 163
E-ring (4) RETAINING RING, TYPE-E(4) - F-2 164
Cutter plate cover COVER,CUTTER PLATE,AB 1 F-2 165
Assist frame sub assembly ASSIST FRAME SUB ASS’Y 1 F-3,4 166
Back frame FRAME,BACK,A 1 F-2 167
Break cap CAP,BREAK,A 1 F-2 168
Left hook button BUTTON,HOOK,L 1 F-2 169
Right hook button BUTTON,HOOK,R 1 F-2 170
Break spring SPRING,BREAK,A 1 F-2 171
Right hook spring SPRING,HOOK,R 1 F-2 172
Left hook spring SPRING,HOOK,L 1 F-2 173
name for service manual name for price list q’ty page ref.#
To Next Page
