Determining Hardware Status
5-6 SmartEdge 1200 Router Hardware Guide
Table 5-4 lists the facility LEDs, which provide status for the Ethernet management port.
Table 5-5 lists the synchronization and external timing LEDs, which indicate the status of any connected
external timing source.
Caution Risk of data loss. Do not remove a CF card from its slot while the CF ACTIVE LED is
blinking; you can lose data that is being transferred to the device if you enter the unmount
/md command (in exec mode) before the data transfer operation is complete. To reduce the
risk, you must wait until the CF ACTIVE LED is off; then enter the unmount /md command
to prepare the device for removal.
Caution Risk of equipment failure. Removing the CF card from its slot without first entering the
unmount /md command (in exec mode) can permanently damage the device and cause the
kernel to crash. To reduce the risk, always enter the unmount /md command before removing
a CF card.
Table 5-4 Facility LEDs on Controller Cards
Label Activity Color Description
LINK/ACTIVITY
LINK/ACT
On Green The Ethernet management link is up.
Blinking Green The Ethernet management link is receiving or transmitting frames.
Off None The Ethernet management link is down.
SPEED On Green The Ethernet management link is operating at 1 Gbps (XCRP4 only)
On Yellow The Ethernet management link is operating at 100 Mbps.
Off None The Ethernet management link is operating at 10 Mbps.
Table 5-5 Synchronization and External Timing LEDs on Controller Cards
Label Activity Color Description
SYNC On Green At least one of the selected synchronization references is in good
condition and is providing reference.
Off None The selected synchronization reference is external, and all external
references have failed. The timing is being internally generated.
EXTERNAL TIMING
LOS PRI
On Yellow The primary input signal from the external equipment has been
configured (provisioned), but is not present.
Off None The primary input signal has not yet been configured or has been
configured and is present.
EXTERNAL TIMING
LOS SEC
On Yellow The secondary input signal from the external equipment has been
configured but is not present.
Off None The secondary input signal has not yet been configured or has been
configured and is present.
