4 MIG/MAG WELDING
0460 896 274
- 22 -
© ESAB AB 2013
4.2 Function explanations for settings
Voltage
Higher voltage increases the arc length and produces a hotter, wider weld pool.
The voltage setting differs between synergy and non synergy modes. In synergy mode, the
voltage is set as a positive or negative offset from the synergic line of the voltage. In non
synergy mode, the voltage value is set as an absolute value.
The voltage is set in the measure, weld data setting or fast mode menus. When the remote
control unit is used, the setting can be adjusted from here.
Wire feed speed
This sets the required feed speed of the filler wire in m/minute.
The wire feed speed is set in the measure, weld data setting or fast mode menus. When the
remote control unit is used, the setting can be adjusted from here.
Inductance
Higher inductance results in a wider weld pool and less spatter. Lower
inductance produces a harsher sound but a stable, concentrated arc.
Inductance is set in the weld data setting menu.
Only applies to MIG/MAG welding with short-/sprayarc.
Regulator type
Affects the short circuit process and heat in the weld.
The setting should not be altered.
Pulse current
The higher of the two current values in the event of pulsed current.
Pulse current is set in the weld data setting menu with the synergy function switched off.
Only applies to MIG/MAG welding with pulsing.
Pulse time
The time the pulse current is on during a pulse period.
Pulse current is set in the weld data setting menu with the synergy function switched off.
Only applies to MIG/MAG welding with pulsing.
Pulse frequency
Time for background current which, along with the time for pulse current, gives the pulse
period.
Pulse frequency is set in the weld data setting menu with the synergy function switched off.
Only applies to MIG/MAG welding with pulsing.
Background current
The lower of the two current values in the event of pulsed current.
Background current is set in the weld data setting menu with the synergy function switched
off.
Only applies to MIG/MAG welding with pulsing.
