4 Configuration Creation | 31
referenced files
layers and instruments
calculated signals
function instances
display name rules
1.
On the Configuration tab of the ribbon, click .
2. Select an existing configuration in the XDX format.
3. In the Import dialog, select the content that you want to import.
If in the target configuration just one measure file is available, the input sig-
nals of the imported calculated signals are mapped to the available file.
If more than one or no measure file is available, the original file is shown as
entry in the File Explorer, but as a missing file. Calculated signals for which
the input signals are not available are indicated with .
Files that are already loaded in the target configuration are skipped. If
another content with the same name already exists, an increment is auto-
matically appended to the nameof the imported content.
Time offsets for measure files are ignored.
Note
If you use calculated signals, which have as input signal another cal-
culated signal, you need to check after the import that the reference to
the input signal is correct.
Note
If you are importing a function instance that uses an FMU for calculation,
you need to check that the FMU file is available on the target computer.
4.1.5 Importing an XDAConfiguration
In INCA and MDA V7.x, configurations are created in XDA format. To reuse these
existing configurations, simply import the XDA file into an V8.6 configuration. The
original XDA file will not be changed by V8.6.
1.
On the Configuration tab of the ribbon, click .
2. Select an existing configuration in XDA format.
3. If V8.6 cannot find the measure file, you can do one of the following:
l
Select the measure file from your file system. The measure file that was
previously used in the XDA file is mapped with the newly selected meas-
ure file. All signals that are contained in the new measure file are dis-
played. Only signals that are not contained in the new measure file are
