5 Layers and Instruments | 86
To scroll and synchronize
To quickly navigate to a specific timestamp in the video, or to synchronize the
Video instrument with other instruments, see "Time Navigation and Syn-
chronization" on the next page.
5.2.9 Battery Imbalance Table
The Battery Imbalance Table is an instrument for voltage analysis. In general, the
battery of an electric vehicle consists of many individual cells. From the complete
battery only the cells with the highest or the lowest voltage value are important,
as these define the overall battery capabilities during charging and discharging.
This instrument allows to identify quickly the signals with the highest deviation
from the average value of many comparable signals.
You can perform the following actions:
"To define the Battery Imbalance Table properties" below
"To assign signals" below
"To replace signals" below
"To sort signals" below
"To delete a signal" on the next page
To define the Battery Imbalance Table properties
The complete set of configuration possibilities for this instrument is available in
the Properties docking window. There, the tooltips provide a detailed description
of the properties and their possible options.
1. Do one of the following:
In the instrument, click .
or
Select the instrument and press ALT+ENTER.
or
In the instrument, right-click and select Properties in the context menu.
To assign signals
To see how you can select the relevant signals and assign these to the desired
instrument, watch our video Selecting Signals.
To know how you can add signals to a new or existing instrument, see "Assigning
Signals to Instruments" on page99.
Note that you can add a signal only once.
To replace signals
For more information, see "To replace a signal" on page101.
To sort signals
If you cklick one of the column headers, you can sort the table contents by this
column in increasing order. With another click on the same column header, the
sorting order is inverted.
MDA V8 | User Guide
