5 Layers and Instruments | 53
3. In the Configuration Manager, right-click a layer and choose Paste.
The instruments are added to this layer. If the name is already in use, it is
extended by an increasing number.
If you have selected a configuration in which the measure file is not avail-
able, the signals in the newly added instruments are indicated as "No-
Match" signals. To avoid a "No-Match" situation, an automatic signal map-
ping is performed in case the "Copy" source and the "Paste" target contain
both exactly one measure file. To resolve a "No-Match" situation, see "To
replace a signal" on page101.
To move an instrument to another layer
To see how you can import an MDA V7 configuration and manage the instrument,
watch our video Import and Layer Handling.
1. In the Configuration Manager, select one or more instruments.
2. Drag and drop the instruments to another layer. For more information
about adding layers, see "To create a new layer" on page47.
To rename an instrument
1. Do one of the following:
l
Right-click the title bar of the instrument in the instrument window.
l
Right-click the instrument in the Configuration Manager.
2. Select Rename.
3. Enter the new name. If the name is not valid, it is displayed with a red frame.
Refer to the tooltip for further information.
To delete an instrument
1. Do one of the following:
l
On the title bar of the instrument window, click the Remove icon. This
icon is also available in the preview of the instrument. For more inform-
ation, see "To display the preview via the layer taskbar" on page49.
l
In the Configuration Manager, right-click the instrument and select
Remove.
To change instrument properties
Instrument properties are stored in your user settings. For more information, see
"User Settings" on page16.
To define the instrument properties, click or use the context menu Prop-
erties.
For each instrument property, the tooltip provides a detailed description of the
properties and their possible options.
5.2.2 Oscilloscope
The oscilloscope can graphically display the course of signals over time.
The oscilloscope is divided into the following areas:
