ETAS MDA V8 - Table

5 Layers and Instruments | 76
To delete a single bound
1. Click on the connection line of the bound.
2.
Click .
3. Select Delete Bound from the drop-down menu.
Alternatively, press DEL.
To delete all bounds
1.
Click .
2. Select Delete All Bounds from the drop-down menu.
5.2.4 Table
The table can display different kinds of signals including enumeration (VTab),
event, and string signals.
The table shows enumeration signals as follows: If a string value is available, it is
displayed. If the enumeration signal has a default value, the table displays the
default value for all numerical values for which there is no associated string value.
If the enumeration signal has no default value and if there is no string value
defined for a numerical value, "n/a" is displayed.
In an MDF measure file, single samples can be marked with an "invalid" flag. In the
table instrument, these invalid samples are marked by a red exclamation mark.
You can perform the following actions:
"To define the table properties" below
"To scroll" on the next page
"To navigate to the start or end of the time range" on the next page
"To move the synchronization timestamp" on the next page
"To show or hide header rows" on the next page
"To reorder columns" on page78
"To fill empty cells" on page78
"To change the number of decimals" on page78
"To change the data representation of a signal" on page78
"To delete signals" on page79
To see how you can use the possibilities of the Table instrument, watch our video
Using the Table.
To define the table properties
The complete set of configuration possibilities for this instrument is available in
the Properties docking window. There, the tooltips provide a detailed description
of the properties and their possible options.
MDA V8 | User Guide
