5 Layers and Instruments | 85
In the GPS Map instrument, right-click the signal and select Remove Track
(s).
or
In the GPS Map instrument, click the signal and press the Del key.
5.2.8 Video
In the Video instrument, the video signal VIDEO_TIMECODE contains only a series
of timestamps. The device name of the video signal is used as link to the actual
video file on the hard disk named <measurefile>_<device_name>.mp4.
Note
The video file names must not be renamed as they are referenced by the cor-
responding MDF file (*.mf4).
The timestamps in the VIDEO_TIMECODE are used for synchronization.
You can perform the following actions:
"To define the Video properties" below
"To display a video signal" below
"To scroll and synchronize" on the next page
To define the Video properties
The complete set of configuration possibilities for this instrument is available in
the Properties docking window. There, the tooltips provide a detailed description
of the properties and their possible options.
1. Do one of the following:
In the instrument, click .
or
Select the instrument and press ALT+ENTER.
or
In the instrument, right-click and select Properties in the context menu.
To display a video signal
1. In the Variable Explorer, select the signal VIDEO_TIMECODE from the cor-
responding device which refers to the camera name.
2. Drag the video signal onto a layer or layer tab of the configuration and
select the Video instrument.
If a signal is already assigned, the new video signal replaces the old one. It
is not possible to assign multiple signals. For more information, see "Assign-
ing Signals to Instruments" on page99.
3. To start the video, click Play and to stop it, click Pause.
MDA V8 | User Guide
