7 Calculations | 104
7 Calculations
Calculations are helpful in displaying and analyzing measure data. MDA supports
two types of calculations:
Functions: use of predefined calculations based onFunctional Mock-up
Units (FMUs, for example created with ASCMO)
Calculated Signals: use of mathematical operators for defining individual
formulas
After creating a calculation, the calculation results are displayed in the Variable
Explorer. They can be selected and used like other measure signals.
7.1 Functions
The Functions tab allows users to use complex calculations based on
ASCMOFunctional Mock-up Units (FMU) in an easy way.
The usage of an FMU is comfortable as you only have to assign the needed input
signals. The calculated outputs are available in the Variable Explorer and can be
used like normal signals.
The Functions editor is divided into the following areas:
