5 Layers and Instruments | 64
unit is not known.
If the signals are dropped from another oscilloscope, the axis assignment
from the source oscilloscope remains unchanged.
To delete axes
1. Right-click a value axis.
2. Click Delete Axis.
The axis is deleted and the signals are deleted from the view.
5.2.2.6 Basic Navigation
To navigate within the oscilloscope, you can perform the following actions:
"To navigate from axis to strip to signal list" below
"To navigate between the strips" below
"To navigate between the axes" below
"To navigate between the signals in the signal list" below
"To navigate to the time slider" below
For more information about the use of the keyboard, see "Operating MDA via Key-
board" on page14.
To navigate from axis to strip to signal list
To quickly navigate horizontally within the oscilloscope use the TAB key and back-
wards press SHIFT+TAB.
To navigate between the strips
1. Bring the focus into the graphical area.
2. To move upwards, press CTRL+PAGE UP.
3. To move downwards, press CTRL+PAGE DOWN.
To navigate between the axes
1. Bring the focus to the axis area.
2. To move to the right, press the ARROW RIGHT key.
3. To move to the left, press the ARROW LEFT key.
To navigate between the signals in the signal list
1. Bring the focus to the signal list.
2. To move upwards, press the ARROW UP key.
3. To move downwards, press the ARROW DOWN key.
To navigate to the time slider
To navigate to the time slider and to enable entering a time value, press CTRL+B.
5.2.2.7 Using Cursors
Cursors are used to get more precise values at certain timestamps. Moreover
cursors enable to determine differences between samples values and in view of
time. The oscilloscope shows directly in the graph the values of the signals at the
MDA V8 | User Guide
