ETAS MDA V8 - Event List

5 Layers and Instruments | 80
To reorder columns
1. Move a column by dragging its column header to the new position within
the table header.
A line between the columns appears together with highlighted areas on
the left and on the right of the line.
2. Select the left or right highlighted area to place the column in front of or
behind this line.
3. Release the mouse button.
To show or hide columns
Each statistical function is shown in a separate column. You can select which
statistical functions shall be displayed.
To distinguish signals that have the same name but are coming from different
devices or different rasters, you can display the device, raster, or unit column.
1.
In the toolbar, click or use the tab Instrument in the Properties win-
dow.
Alist of all columns appears.
2. To show or hide a column, select or clear the checkbox of the respective
column name in the list.
To increase and decrease the number of decimals
1. Mark the columns for which you want to change the number of decimal
places.
2. In the toolbar, click one of the following icons:
l
To show more decimal places, click .
l
To show fewer decimal places, click .
To copy signal name and other meta information
To know how you can copy the signal name and other meta information to other
applications, see "Reusing the Signal Name in Other Applications" on page102.
To delete signals
1. Select one or more signals. Do one of the following:
l
In the instrument, mark one or more rows.
l
In the Configuration Manager, mark one or more signals.
2. In the context menu, select Remove.
5.2.6 Event List
The Event List shows all value changes of the assigned signals. Events can be
shown for Boolean signals as well as for numeric, enumerations, and string sig-
nals. String signals are, for example, user comments during recording. For
Boolean and numeric signals a rising respective falling edge icon is shown
depending on an increasing respective decreasing physical value. For string and
enumeration signals, only string values with an event icon are shown.
