6 Signal Selection | 98
To reset filters
You can perform the following actions:
Clear all filters
To clear all filters in categories, columns, and search box , click in the
area of the variables list.
Disabled filters in categories remain unchanged.
Filters in columns
i.
To reset filters of a specific column, click .
ii. In the drop-down list, select the Select all checkbox.
Filters in a category
i.
To clear the filters in one category, click .
ii.
To deactivate the selected filters, click .
The original selection is maintained, even if you clear the filters using
the icon.
To sort signals per column in the Variable Explorer
In the Variable Explorer, the Display Name column is sorted by default. If you
want to sort another column, click the header of the respective column. The cur-
rently sorted column is indicated by a blue color label and underline. The sorting
is not case-sensitive. If the entries start with a number, they are ordered alpha-
numerically.
6.4 Extracting Bits from a Signal
Some signals can be interpreted as a combination of 1-bit signals. For example, a
byte signal contains eight different, independent status bits. Each bit represents
one specific status information. For such signals, rather the individual bit signals
are relevant.
To see how you can extract individual bits from a signal and rename them, watch
our video Extracting Bits from a Signal.
To extract these from the complete signal block, proceed as follows:
1. In the Variable Explorer, select the signal from which the individual bits shall
be extracted.
2. In the context menu, select Generate Bit Signals.
3. Select one or more bits.
The number of checkboxes depends on the data type of the selected vari-
able.
4. Click Generate.
