5 Layers and Instruments | 71
Select the instrument and press ALT+ENTER.
or
In the instrument, right-click and select Properties in the context menu.
In the following, only the more advanced functions are explained in further detail.
For more information about synchronizing, scrolling, and zooming, see "Time Nav-
igation and Synchronization" on page87.
5.2.3.1 Adjusting Signals
You can perform the following actions:
To delete a signal
1. Do one of the following:
l
If only one strip exists and you want to delete its signal, right-click the y-
axis.
l
If you want to delete the signal of the x-axis, right-click the x-axis.
2. Select Remove Signal.
5.2.3.2 Zooming
To see how you can use the possibilities of the Scatter Plot instrument, watch
our video Using the Scatter Plot.
You can perform the following actions:
"To define the zoom area" below
"To show the complete value range" below
To define the zoom area
1. Press either CTRL and the left mouse button or just the right mouse button.
2. While keeping the button pressed, move the cursor horizontally or ver-
tically.
The selected zoom area is highlighted.
To show the complete value range
If you perform the following steps, only the signal values are considered that are
part of the currently visible time range in the time slider. If all samples of the sig-
nal from the whole measure file shall be considered, you must additionally adapt
the time range. For more information, see "To show the full time range of the
measure file" on page92.
1.
If you want to show the complete value range for all strips, click .
or
1. If you want to show the complete value range of a specific signal, right-
click its axis.
2. Select Zoom to Complete Value Range.
or
MDA V8 | User Guide
