6 Signal Selection | 97
1.
In the header of the column that you want to filter, click .
A list with the possible filter criteria for this column is displayed.
In the Raster column, the filter for variables that have been recorded in sev-
eral rasters works as follows:
l
If variables were recorded in INCA in several rasters and are stored into
one single file, the variables can be filtered by the combined raster only
(combined per + symbol) and not by the different individual rasters.
l
If variables were recorded in several files and exported into one com-
mon file, the variables are shown as list separated by a semicolon and
can be filtered per raster. The filter option allows you only to select a
single value (e.g. "0.1"). The variable is shown if one of its rasters is used
for filtering.
2. Clear the checkboxes of those entries that you do not want to be dis-
played in the list. When checking several filters within the list, a logical OR
is applied.
3. Click Apply.
The Variable Explorer table displays the rows which match the defined filter
criteria.
4. You can repeat the steps 1-3 for other columns.
A logical AND is applied between the filters of the different columns.
All column filters possibilities will be integrated in the filters per categories.
Filtering per categories
To see the desired signals in the variables list, check within one category
the corresponding entries.
You can disable all filters in a category. The original selection is maintained,
but has no effect on the variables list, even if you clear filters using the
icon.
Filters possibilities in categories, columns and search box can be applied in
combination (using a logical AND). In the header of the Display Name
column, the number of matching signals out of the total number of signals
is shown.
To filter used/unused signals
In the Variable Explorer toolbar, click .
There are three different states of this button:
Shows all used signals, i.e. signals assigned to an instrument or used for a
calculated signal
Shows all unused signals, i.e. signals not assigned to an instrument or not
used for a calculated signal
Shows all used and unused signals
